Name: OH3 Magnetic Drive Pump
Brand: LUBOR PUMP
Availability: InStock

Specification and Performance of OH3 Magnetic Drive Pump

MZF-G Standard OH3 Pipe Line Vertical Magnetic Drive Pump

Vertical installation suitable for pipeline pressurization

Standard	API685
Shaft	Vertical
Impeller	Open/semi open/closed
Capacity	Up to 1000 m³/h / 4400 US gpm
Head	Up to 200m / 656ft
Frequency	50/60Hz
Temperature	Up to 450℃/900℉
Discharge size	25 to 400 mm / 1 to 16 inches
Pressure	Up to 100 bar / 1450 psi
Drive	Motor

Advantages of OH3 Magnetic Drive Pump

Leak - proof

Magnetic drive pumps use magnetic coupling for power transmission, eliminating mechanical seals. This design makes them excellent at preventing liquid leakage, especially for hazardous, corrosive, or toxic fluids.

Low - maintenance

With fewer parts subject to wear and tear, magnetic pumps generally require less maintenance. There's no need to frequently replace mechanical seals, reducing maintenance costs and downtime.

Good Sealing

The magnetic coupling provides a reliable seal. It can maintain the integrity of the fluid system, preventing gas or vapor escape, which is important for processes demanding high containment.

Corrosion - resistant

Often made of corrosion - resistant materials like stainless steel, plastic, or ceramic, they can handle a wide range of corrosive media and work well in harsh chemical environments.

Quiet Operation

The lack of direct mechanical contact between the motor and the impeller means less vibration and noise during operation.

Energy - efficient

Some magnetic pumps are energy - efficient. Their design can lead to lower energy consumption, especially in long - term pumping applications.

Overload Protection

Magnetic couplings can offer a certain level of overload protection. In case of sudden load increases or impeller jams, the magnetic coupling may slip to prevent damage to the motor and other components.
