Submersible Sewage Pump

Specification and Performance of Submersible Sewage Pump

Feathers

I.Intelligent water pump, cloud remote monitoring

Pump internal integrated vibration sensor, bearing temperature PT100, winding temperature PT100, oil chamber leakage, motor cavity leakage and other protection components, all-round monitoring of pump operation, and can be

real-time data display through the intelligent control cabinet, alarm or stop automatic operation.At the same time, the remote monitoring operation and maintenance platform of Shanghai kaiquan intelligent cloud can be logged in for monitoring and operation and maintenance operation.

II. Unique non-overload hydraulic design, innovative technology of sewage treatment pump, innovative design concept of high-efficiency non-overload hydraulic model, as well as the capacity design of sewage pump.Completely solve the operation of the pump worries. No overload hydraulic technology features, maximum power point out of the efficient zone, smooth operation, no

vibration. Impeller passing capacity: impeller through a large number of CFD research and analysis and testing, so that the impeller blade and solid through the ability to achieve the best balance, the unique design of the flow components to ensure the solid through the fiber and the anti-winding.

III.the original pump seal design, ensure the pump long-term reliable operation seal to ensure that the stator cavity does not water damage the motor.

IV.Excellent mechanical seal Imported borgmann mechanical seal is adopted, the pump head seal material is silicon carbide to tungsten carbide,

providing the maximum wear resistance, and the design service life of the pump head seal is 15000 hours

Mechanical seal self-cleaning technology

Two single-end mechanical seals are installed in series. Special spiral grooves or small crevice are adopted at the pump cover to prevent solid particles from depositing on the pump side mechanical seals, so as to achieve the self cleaning function of the mechanical seals and extend the service life of the mechanical seals
